LED Pixel Protocol UCS2904

Overview

This pixel protocol was designed by Lianxinke in China. UCS2904 offers all the same features as its RGB version, UCS2903, but is dedicated to RGBW. The control circuit comes in a SOP8 package, allowing for more flexibility with LED choice.

UCS2904 graphic - Advatek Lighting

UCS2904 graphic

Specifications

PixLite Mk1

PixLite Mk2

PixLite Mk3

Clock Type

Data-Only

Color Resolution

Bits

Current Control

Physical Package

SOP8

RGB

RBGW

Input Voltage

5V

Output Pixel Voltage

24V

PWM Rate

1800Hz

Suitable Camera

Up to 60fps

Data Transfer Rate

800kbps

Redundant Data Line

Considerations for Use

Advantages

  • Up to 24V, allowing for very long cable lengths
  • High PWM rate allows for filming these pixels with cameras up to 60fps
  • Presence of white LED allows for higher brightness and more color mixing options

Disadvantages

  • Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow
  • Only 8 bits of data for each color makes dimming curves less smooth
  • No redundancy in data

PixLite Support

Are you looking for UCS2904 pixel drivers that work with Art-Net or sACN?

All PixLite Mk2 and Mk3 products support UCS2904 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
