LED Pixel Protocol SK9822

Overview

This pixel protocol was designed by OPSCO in China. It is an improved design of its previous version, SK6822, using a clock line to achieve faster refresh rates and improved optics to achieve a higher PWM rate, which is why SK9822 is one of the most common protocols for pixel lighting displays. The control circuit and LEDs are integrated in a 5050 SMD package, which provides a small physical footprint for each pixel.

Current Control

SK9822 has the ability to digitally control the current of the connected LEDs. Use the 5-bit global current control to lower the brightness without sacrificing resolution. This global brightness control can be set when configuring your PixLite Mk3 controller.

Specifications

PixLite Mk1

PixLite Mk2

PixLite Mk3

Clock Type

Clocked

Color Resolution

Bits

Current Control

Global: Bits

Physical Package

SMD5050 with integrated LEDs

RGB

RBGW

Input Voltage

5V

Output Pixel Voltage

5V

PWM Rate

4600Hz

Suitable Camera

Up to 154fps

Data Transfer Rate

N/A

Redundant Data Line

Colors

Color

Wavelength

Red

620 – 630 nm

Green

515 – 525 nm

Blue

460 – 470 nm

Considerations for Use

Advantages

  • Presence of a clock allows for faster refresh rates
  • Very high PWM rate allows for filming these pixels with cameras up to 154fps

Disadvantages

  • Only 8 bits of data for each color makes dimming curves less smooth
  • Limited to 5V, causing short cable lengths
  • No redundancy in data

PixLite Support

Are you looking for SK9822 pixel drivers that work with Art-Net or sACN?

All PixLite Mk2 and Mk3 products support SK9822 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
