LED Pixel Protocol MBI6023

Overview

This pixel protocol was designed by Macroblock in Taiwan. MBI6023 is very similar to MBI6020, but also offers the ability to drive up to 4x RGB pixels per chip, and a slightly higher PWM rate. Scrambled-PWM technology enhances pulse width modulation by scrambling the “on” time into several “on” periods. This increases the effective PWM rate, allowing MBI6023 pixels to look good on almost every camera. The control circuit comes in a SOP24 package, allowing for more flexibility with LED choice.

Specifications

PixLite Mk1

PixLite Mk2

PixLite Mk3

Clock Type

Clocked

Color Resolution

10 Bits

Current Control

Physical Package

SOP24

RGB

RBGW

Input Voltage

5V

Output Pixel Voltage

12V

PWM Rate

11,718Hz

Suitable Camera

Up to 391fps

Data Transfer Rate

N/A

Redundant Data Line

Considerations for Use

Advantages

  • Presence of a clock allows for faster refresh rates
  • Very high PWM rate allows for filming these pixels with cameras up to 391fps
  • Up to 12V, allowing for long cable lengths
  • 10 bits of data for each color makes dimming curves more smooth

Disadvantages

  • No redundancy in data

PixLite Support

Are you looking for MBI6023 pixel drivers that work with Art-Net or sACN?

All PixLite Mk2 and Mk3 products support MBI6023 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
