LED Pixel Protocol MBI6020

Overview

This pixel protocol was designed by Macroblock in Taiwan. Scrambled-PWM technology enhances pulse width modulation by scrambling the “on” time into several “on” periods. This increases the effective PWM rate, allowing MBI6020 pixels to look good on almost every camera. The control circuit comes in a SOP16 package, allowing for more flexibility with LED choice.

Specifications

PixLite Mk1

PixLite Mk2

PixLite Mk3

Clock Type

Clocked

Color Resolution

10 Bits

Current Control

Physical Package

SOP16

RGB

RBGW

Input Voltage

5V

Output Pixel Voltage

12V

PWM Rate

9766Hz

Suitable Camera

Up to 326fps

Data Transfer Rate

N/A

Redundant Data Line

Considerations for Use

Advantages

  • Presence of a clock allows for faster refresh rates
  • Very high PWM rate allows for filming these pixels with cameras up to 326fps
  • Up to 12V, allowing for long cable lengths
  • 10 bits of data for each color makes dimming curves more smooth

Disadvantages

  • No redundancy in data

PixLite Support

Are you looking for MBI6020 pixel drivers that work with Art-Net or sACN?

All PixLite Mk1, Mk2, and Mk3 products support MBI6020 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
