LED Pixel Protocol APA104

Overview

This pixel protocol was designed by APA Electronic Co. in Taiwan. Also known as “Superled”, APA104 is one of the most common protocols for pixel lighting displays. The control circuit and LEDs are integrated in a 5050 SMD package, which provides a small physical footprint for each pixel.

Specifications

PixLite Mk1

PixLite Mk2

PixLite Mk3

Clock Type

Data-Only

Color Resolution

Bits

Current Control

Physical Package

SMD5050 with integrated LEDs

RGB

RBGW

Input Voltage

5V

Output Pixel Voltage

12V

PWM Rate

400Hz

Suitable Camera

Unsuitable for cameras

Data Transfer Rate

800kbps

Redundant Data Line

Colors

Color

Brightness

Wavelength

Red

390 – 420 mcd

620 – 625 nm

Green

660 – 720 mcd

522 – 525 nm

Blue

180 – 200 mcd

465 – 467 nm

Considerations for Use

Advantages

  • Up to 12V, allowing for long cable lengths

Disadvantages

  • Low PWM rate makes theses pixels unsuitable for cameras
  • Data-only restricts refresh rates to be limited by the speed of the protocol, which can be slow
  • Only 8 bits of data for each color makes dimming curves less smooth
  • No redundancy in data

PixLite Support

Are you looking for APA104 pixel drivers that work with Art-Net or sACN?

All PixLite Mk2 and Mk3 products support APA104 as an available Pixel IC type, so get in touch with us to find out how the lighting specialists at Advatek can support you in your pixel lighting project.
